The Cat 289D is a compact track loader with an operating weight of 10,533 lb, a rated operating capacity of 2,660 lb (35% tipping load) and a 74.3 HP Cat C3.3B turbo engine. At IronPower Industries, used 289D units (2015–2019, about 1,650–2,150 hours) have sold between $38,500 and $41,500.
320160
$38,800
2134
2019
10090
$41,500
1802
2017
| Engine | Cat C3.3B DIT turbo |
|---|---|
| Gross / net power | 74.3 HP / 72.9 HP |
| Operating weight | 10,533 lb |
| Rated operating capacity | 2,660 lb (35%) · 3,800 lb (50%) |
| Tipping load | 7,600 lb |
| Breakout force (tilt) | 7,291 lb |
| Hydraulic flow (High Flow XPS) | 32 gpm |
| Hydraulic pressure | 3,335 psi standard · 4,061 psi High Flow XPS |
| Travel speed | 4.5 mph (1-speed) · 7 mph (2-speed) |
| Length with bucket on ground | 146.2 in |
| Width | 76 in (400 mm tracks) · 78 in (450 mm tracks) |
| Height to top of cab | 83.2 in |
| Ground pressure | 5.2 psi (400 mm) · 4.6 psi (450 mm) |
| Fuel tank | 24.8 gal |
Source: manufacturer specifications.
Based on IronPower’s own sales: enclosed-cab 289D units with A/C, several with high flow, 2015–2019 and about 1,650–2,150 hours, sold for $38,500–$41,500. Every unit is inspected at our yard in Hialeah, FL, and can be financed and shipped nationwide.
The Cat 289D has an operating weight of 10,533 lb. Use a truck and trailer rated for that weight plus the trailer and attachments.
The rated operating capacity is 2,660 lb at 35% of tipping load, or 3,800 lb at 50%. Tipping load is 7,600 lb.
The 289D uses a turbocharged Cat C3.3B engine rated at 74.3 gross HP (72.9 net HP).
Both use the 74.3 HP Cat C3.3B engine and the same frame size. The newer 289D3 is slightly heavier (10,688 lb) and rated higher: 2,890 lb at 35% versus 2,660 lb on the 289D.
For a well-maintained compact track loader, 1,500 to 2,500 hours is mid-life. Check undercarriage and track wear, hydraulic leaks and service records.
Yes. IronPower Industries ships compact track loaders nationwide from Hialeah, Florida, and offers financing on approved credit.
